Main Parameters of Engine
Main parameters of engine
China European Standard
Engine type Four stroke, single cylinder, four valves, double spark plugs
Cooling method
Air-cooled
Cylinder diameter stroke
54×58.8mm
54×54.5mm
Displacement 134.6 ml 125ml
Compression ratio 9.8
Maximum net power /
corresponding speed
9.3Kw/9000 r/min 8.2kw/9500rpm
Maximum torque /
corresponding speed
10.3 N•m /7000 r/min 10Nm/7000rpm
Injection type
Electronic fuel injection
Start method Electrical starting
Idle speed
1500r/min
Spark plug model
A7RC
Maximum lift range of
intake/exhaust valves,
opening and closing
angle with respect to the
dead point, and valve
clearance
Intake valve
Maximum lift range 6.2mm
Opening angle 41°
Closing angle 71°
Exhaust valve
Maximum lift range 6.1mm
Opening angle 64°
Closing angle
34°
Lubrication method Splash lubrication
Amount of oil added 1.1L
- 197 -
