Lighting System
Headlight
Note
LED light source is used for the light. If the high
beam or low beam position lamp is not on, the
entire headlight needs to be replaced.
●Disassemble the headlight [A] (see “Frame”-“Fairing
Disassembly”)
●After replacing headlight, adjust the condensation of
headlight (see “Headlight Condensation Inspection
Part” in chapter “Regular Maintenance”)
Tail light
Remove the tail light [A] (see “Frame” –
“Disassembling Cover”)
- 450 -
