●After the connection between two ends of throttle
cable steel cable, the steel cable shall be able to move
freely [A].
If the steel cable cannot move smoothly after the
lubricant is applied, the cable has been worn [B] or the
throttle cable jacket is broken [C], the throttle cable
must be replaced.
Check Tightness of Bolt, Nut and Fastener
Check the tightness of the bolts and nuts listed below.
In addition, check whether all the cotter pins are in
place and in good condition.
Remark
The tightness of engine fasteners shall be
checked when the engine is cooled (indoor
temperature).
If the fasteners are loose, tighten them according to
the specified tightening order and tightening torque.
For the specifications on torque, see the corresponding
chapters. Refer to the “Standard Torque Table” if the
tightening torque is not described
in the relevant
chapters. When any fastener is tightened, tighten it for
1/2 circle and then continue to tighten it.
If the cotter pin is broken, it must be replaced with a
new one.
- 92 -

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Benelli TNT125 and is the answer not in the manual?

Benelli TNT125 Specifications

General IconGeneral
Displacement125 cc
Transmission5-speed
Fuel SystemEFI
Fuel Capacity7.2 liters
Seat Height780 mm
Dry Weight116 kg
Bore x Stroke54 mm x 54.5 mm
Starting SystemElectric
Wheelbase1215 mm
Engine TypeSingle cylinder, 4-stroke, air-cooled
Front SuspensionUpside-down fork
Front BrakeSingle disc
Rear BrakeSingle disc
Front Tire120/70-12
Rear Tire130/70-12
Max Power8.2 kW (11.1 Cv) @ 9500 rpm
Rear SuspensionSwing arm with lateral shock absorber with adjustable spring preload
