Technical Parameters
Specifications
Item Stanard value Limit value
Starter gear wheel
Outer diameter of shaft section
49.175～49.2
49.1
Torque Value
Left cover monting bolt 12N•m
Left cover plate monting bolt
10N•m
Flywheel lock nut 90-100N•m
St
ator component mounting bolt 10N•m
Tr
igger head mounting bolt 7N•m
St
arter motor mounting bolt 12N•m
Troubleshooting
Engine cannot start
·Overrunning clutch is damaged
· Starter gear wheel or idle gear is damaged
· Starter motor is damaged
- 272 -
