Benelli TNT125 Service Manual

Technical Parameters
Item
Standard
Use limit
Oil capacity
When replacing oil 1L
＿
When disassembling 1.1L
＿
Fuel pump rotor
Radial clearance between internal
and external rotors
0.005-0.095 0.15
Clearance between external rotor
and pump body
0.11-0.163 0.24
Clearance of end face of rotor 0.07-0.12 0.15
Torque Value
Mounting screw of fuel pump 10N•m
Mounting screw of fuel pump base
5N•m
Apply locking agent
- 203 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
