Benelli TNT125 Service Manual

●Disassemble:
Brake pad [A]
Installing Rear Brake Pad
●Push the calipers inward as far as possible.
●Install:
The operations should be conducted in reverse order of
disassembly.
●Install calipers (see “Installing Calipers”)
●Check: brake fluid level [A], if it is lower than the
minimum score, add sufficient brake fluid
recommended until it reaches the correct level.
●Check: brake handle operation, if the brake handle
feels loose and soft, or light and soft, empty the air
from the brake circuit.
Warning
Grasp the brake lever, until brake pad is against
the brake disc, so that
the brake lever can
function as normal. Do not ride the motorcycle
before you complete the above steps! Because if
you do not complete the above operation, brake
may not work normally when being used for the
first time and thus danger is caused.
Checking the Wear of Brake Pad
●See “Regular Maintenance”—“Checking the Wear of Brake pad”.
Master Cylinder
Disassembling Front Master Cylinder
●
Disassemble the mounting bolt of front master
cylinder [A].
●Disconnect the connector of front brake lamp switch.
N
ote
If brake fluid spills out, please rinse immediately!
- 329 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
