Benelli TNT125 Service Manual

Checking Hub Bearing
Because the error of hub bearing is very small,
generally it is unable to measure the clearance
Remark
○Do not remove any bearing for check, because the
bearing must be replaced with one after removal.
●If it needs to check whether there is an axial clearance
in the bearing, it is jammed or blocked during the
rotation, please rotate each bearing in the hub back and
forth [A]!
★
If the bearing cannot rotate smoothly, please replace
the bearing!
●Inspect the bearing seal [B] for damage or leaks.
★
If there is damage or leak in bearing seal, please
replace the bearing!
Hub Bearing Lubrication
Remark
○Because there is lubricant in hub bearing and it is
sealed, it does not need to add lubricating oil to hub
bearing.
- 299 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
