Benelli TNT125 Service Manual

General Technical Parameter
Item BJ125-3E
Dimension
China Enrope and Non-Europe:
Overall length 1840mm 1770mm
Overall width 755mm 760mm
Overall height
1025mm
1025mm
Wheel base
1215mm
1215mm
Height above ground 160mm 160mm
Height of seat 790mm 790mm
Curb mass : 121kg 124
Front wheel axle load 60kg
Rear wheel axle load
61kg
Capacity of fuel tank 7.2±0.3L 7.2±0.3L
Rated maximum payload 150kg 177kg
Performance
Minimum turning radius 5m
European Standard
1-cylinder/4-stroke/4-valve
Air cooling type
54×58.8mm
54×54.5mm
135ml
125ml
9.8：
1
9.3kW/9000rpm 8.2kw/9500rpm
10.8N•m/7000rpm 10Nm/7000rpm
1500±100rpm/min
1.25MPa/1500rpm
EFI
Electric starter
TLI
Electronic advance angle control (there is electronic igniter in ECU)
From 10° BTDC @1 100 r/min (rpm)
A7RC
41°
71°
292°
64°
34°
278°
Force-feed and splash
Engine
Type
Cooling system
Cylinder diameter and travel
Displacement
Compression ratio
Maximum horsepower
Maximum torque
Idle speed-rpm
Cylinder pressure
Fuel system
Start-up system
Ignition system
Ignition advance angle
control Ignition timing
Spark plug
Valve timing :
Air inlet :
Open valve
Closed valve
Total time interval
Air exhaust:
Open valve
Closed valve
Total time interval
Lubrication system
Oil fliter
Oil filtering type
- 40 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
