Benelli TNT125 - Basic Specification

To Next Page

To Previous Page

Basic Specification

China

Dimension

Standard

Overall length 1840mm

Overall width

755mm

Overall height

1025mm

Wheel base 1215mm

Enr

ope and Non-Europe:
