Benelli TNT125 - Installing Starter Mechanism

To Next Page

To Previous Page

●

Loosen the starter motor mounting bolt and take off

the starter motor

Installing Starter Mechanism

●

Install starter mechanism in the reverse order of

disassembly.

Starter motor

mounting bolt

Starter motor

- 275 -
