Installing Drive System
Assembling Primary Shaft Component and Aauxiliary Shaft Component
Install
S
pline washer
R
etainer
N
ote:
Make sure that the sharp edge of retainer
AE A is
located on the opposite side from spline washer and
the opening of retainer A
b
E A is located on the spline
slot of shaft
A
cE
Install
2nd
Gear of primary shaft
Note:
Install the 2nd Gear of primary shaft on the primary
shaft
, and then measure after compaction, as
shown in the figure: A
a
E A 77.677.8mm
- 268 -
