Benelli TNT125 Service Manual

Installing Rear Wheel
●Apply high temperature grease to the edge of oil seal.
●Put shaft sleeve at two sides of hub.
Shaft sleeve at right side [A]
Shaft sleeve at left side [B]
●Install drive chain at the rear sprocket.
●Install calipers bracket [A] to the swing arm stop
block [B].
●Insert the rear shaft from the left side of wheel, and
then tighten rear shaft nut.
Locking torque of rear wheel axle nut: 90N·m
●Adjust the slackness of drive chain after installing the
rear wheel (see “Regular Maintenance”—
“Check the
Slackness of Drive Chain”).
● Install the rear calipers (see “Brake” —“Installing
Calipers”).
●Mount the rear wheel speed sensor.
● Check whether the rear brake is normal (see “Regular
Maintenance”—
“Check Whether the Brake is
Normal”).
Warning
Tread on brake pedal, until the brake pad is
against the brake disc, so that the brake pedal
can function as normal. Do not ride the
motorcycle before you complete the above steps!
Because if you do not complete the above
operation, brake may not work normally when
being used for the first time and thus danger is
caused.
- 290 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
