Benelli TNT125 Service Manual

Torque and Locking Agent
Main Locking Torque Specifications
The following table shows the locking torque of the main fasteners that are to be used with locking agent or
silicone sealants.
The letters in “Remark” column have the following meanings:
AL: Tighten the mounting bolts alternately twice in accordance with the higher locking torque.
G: Apply grease.
L: Apply thread fastening adhesive.
M: Apply grease containing molybdenum disulfide.
MO: Apply oil solvent containing molybdenum disulfide. (Mixture of oil and grease containing molybdenum
disulfide prepared in a weight ratio of 10: 1)
R: Replacement parts.
S: Observe the specified tightening sequence.
Si: Apply silicone grease.
SS: Apply silicone sealant.
Fastener
Torque
Remark
N·m
kgf·m
Fuel Injection System (EFI)
Air filter element cover bolts
6
0.70
Air filter cartridge support screw
6
0.70
Camshaft position sensor bolt
10
1.0
Crankshaft sensor bolt
5.9
0.60
Pipe clamp bolt
2.0
0.20
Fuel tank mounting bolt
10
1.0
Fuel pump bolt
4
0.4
S
Intake pressure sensor bracket screw
10
1.0
Oxygen sensor
25
2.5
ECU bolt
3.9
0.40
L
Speed sensor bolt
3.9
0.40
L
Engine cylinder head and cylinder head cover
Cylinder head cover bolt
10
1.0
L
Camshaft sprocket mounting bolt
15
1.5
L
Camshaft cover bolt
10
1.0
S
Camshaft timing chain guide chain bolt
12
1.2
S
Camshaft timing chain tensioner mounting bolt
10
1.0
Cylinder head bolt (M11)
50
5.0
L
（
3
）
Exhaust pipe mounting bolt
22
2.2
Spark plug
25
2.5
10
1.0
L
（
1
）
120
12.0
R
Clutch
Clutch cover bolt
Clutch hub nut
Clutch spring bolt
10
1.0
25-28 2.5-2.8
10 1.0
10
1.0
Engine lubrication system
Oil
drain bolt
Plug of fuel filler
Fuel pump cover bolt
- 48 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
