Benelli TNT125 Service Manual

(Continued)
Fastener
Torque
Remark
N·m
kgf·m
Crankshaft / drive mechanism
Balancer shaft fastening nut M14
40
4.0
Mould closing bolt M6
12
1.2
S
Crankcase bolt
12
1.2
S
Flywheel locking nut M25
100
10.0
Driving gear nutM20
80
8.0
Shifting and positioning plate bolt M6
12
1.2
Disassembly / installation of engine
Front bracket bolt of engine (M10)
Upper bracket bolt of engine (M8)
45
4.5
S
Upper mounting bolt of engine (M10)
25
2.5
S
Front mounting bolt of engine (M10)
50
5.0
AL
、
S
Rear mounting bolt of engine (M10)
50
5.0
AL
、
S
Wheels / Tires
Front axle mounting bolt
20
2.0
AL
Front axle
80
8.0
Si
Front axle bolt
80
8.0
Rear axle
90
9.0
Si
Rear axle bolt
90
9.0
Final drive mechanism
Chain upper limit block bolt
Chain protection block bolt
10
1.0
L
Engine sprocket cover bolt
10
1.0
L
Engine sprocket Nut
10
1.0
Rear sprocket nut
125
12.5
MO
Brake
Release valve
Brake hose hollow bolt
7.8
0.80
Brake handle pivot axle bolt
25
2.5
Brake handle pivot axle bolt locking nut
2
0.2
Si
Brake pedal bolt
6
0.6
Front brake disc mounting bolt
22
2.2
Front brake light switch screw
27
2.7
L
Front brake upper pump oil reservoir cover fixing
screw
1.2
0.12
Front caliper mounting bolt
1.2
0.12
Front caliper mounting bolt
27
2.8
L
Front upper pump bleed valve
34
3.5
Front upper pump mounting bolt
7.8
0.80
Rear brake disc mounting bolt
11
1.1
S
Rear caliper mounting bolt
27
2.8
L
Rear caliper mounting bolt
25
2.5
Rear upper pump mounting bolt
10
1.0
Rear upper pump pull rod locking nut
10
1.0
- 49 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
