Benelli TNT125 Service Manual

(Continued)
Fastener
Torque
Remark
N·m
kgf·m
Suspension system
Front axle mounting bolt
22
2.0
Front shock absorber mounting bolt (upper)
22
3.1
AL
Front shock absorber mounting bolt (lower)
22
2.2
Front shock absorber top plug
28
2.8
Front damper piston rod nut
45
4.5
Rear shock absorber bolt (upper)
45
4.5
Rear shock absorber bolt (lower)
45
4.5
Rear shock absorber nut (lower)
90
9.0
Rear swing arm shaft nut
90
9.0
Steering system
Steering rod compression nut
35
3.5
AL
Steering rod locking nut
24
2.4
AL
Upper connection plate fastening screw
50
5.0
Handle positioning double-end stud fixing nut
45
4.5
AL
Handle bolt
25
2.5
L
Left switch compression screw
3.5
0.35
Right switch compression screw
3.5
0.35
Left handle rear compression bolt
10
1.0
Left handle pivot axle bolt
6
0.6
Left handle pivot axle bolt locking nut
6
0.6
Balance block bolt
10
1.0
Frame
Front seat cushion bolt
10
1.0
Rear seat cushion bolt
10
1.0
Rear armrest bolt
22
2.2
Rear baffle bracket mounting seat mounting bolt
10
1.0
Rear baffle bracket mounting bolt
10
1.0
Front left pedal bracket bolt
45
4.5
Shift lever mounting seat bolt
10
1.0
Shift assembly bolt
10
1.0
Front right pedal bracket bolt
45
4.5
Rear left pedal bracket bolt
25
2.5
Rear right pedal bracket bolt
25
2.5
Muffler cylinder mounting bolt
22
2.2
Muffler cylinder rear bolt
22
2.2
Muffler cylinder rear mounting bolt
22
2.2
Single-supporting bolt
50
5.0
Single-supporting bolt locking nut
45
4.5
Single-supporting flameout switch bolt
6
0.6
Battery bracket bolt
10
1.0
- 50 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
