Benelli TNT125 Service Manual

- 184 -
Simple Troubleshooting
Please follow the following steps to repair EFI
system. To repair fault in one step, the subsequent
steps may be stopped. And then use diagnostic
apparatus to conduct inspection and acceptance and
clear fault code according to section “Engine Working
Data Flow Displayed by Diagnostic Apparatus”.
When using diagnostic apparatus, the voltage of
storage battery should not be lower than 8.5 V.
Daily Use and Maintenance
 Gasoline should be high quality without lead.
 ECU has a moisture-proof function, but
high-pressure water gun should not be used to
rinse its shell.
 The petrol filter should be changed every 18,000
km.
 Under normal conditions of use, clean the throttle
body every 10,000 km or 1 year.

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
