wire terminals of voltage stabilizer (white 1, white 2,
white 3); the pointer table shows a certain value (range
of 0.1-
0.5V), otherwise it indicates that the voltage
stabilizer is damaged and needs to be replaced.
3. Connect the red probe to the black wire terminal at
the voltage stabilizer port and connect the black probe
to the white wire terminals of voltage stabilizer (white
1, white 2, white 3); the pointer table shows a certain
value (range of 0.3-0.8V), otherwise it indicates that the
voltage stabilizer is damaged and needs to be replaced.
Rectifier Installation
Install the rectifier in reverse order of disassembly
order
Fastening torque of rectifier bolt: 10 N·m
