Benelli TNT125 Service Manual

Assembling Master Cylinder
●
Before assembly, use the brake fluid or alcohol to
clean all parts, including the master cylinder.
Note
Except for the brake pad and disc brake, other
brake parts can only be cleaned by disc brake
fluid,
isopropyl alcohol or ethanol. Do not use any
other fluid to clean above parts. Gasoline, oil or
any other petroleum distillate can corrode the
rubber parts. If oil splashes onto any part, it will
be difficult to clean it thoroughly and the rubber
parts ins
ide the disc brake will be corroded
eventually.
●Apply the brake fluid to the new parts and inner wall
of brake cylinder.
●Be careful not to scratch the piston or inner wall of
brake cylinder.
●Apply silicone grease to the brake handle pivot shaft
bolt.
●Tighten the brake handle pivot shaft bolt and lock nut.
Locking torque of front brake handle pivot shaft
bolt: 1.0 N·m;
Locking torque of front brake handle pivot shaft
bolt lock nut: 5.9 N·m
- 108 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
