Benelli TNT125 Service Manual

N
o. Chinese name and specifications
Torque
Remark
N·m kgf·m
1 Rear wheel axle
90 9.0 Si
2 Rear shock absorber mounting washer
3 Rear wheel left shaft sleeve
Si
4 Self-locking nut M10×1.25
45 4.5
5 Sprocket
6 Chain 428HG-1×116
7 Dust ring component
Si R
8 Rolling bearing 6204-2RS
9 Chain drive axle sleeve
Si
10 Sprocket hub mounting washer
11 Sprocket hub
12 Sprocket mounting bolt 45 4.5
13 Rear wheel damper
14 Rolling bearing 6202-2RS
Si
15 Rear wheel middle axle sleeve
Si
16 Rolling bearing 6302-2RS
Si
17 Front wheel right oil seal component
Si R
18 Valve
R
19 Rear rim
Si
20 Vacuum tire 130/70-12
21 Rear wheel right bushing
Si
22 Rear hydraulic brake disc
23 Bolt M8×24
22
2.2
L
24 Self-locking nut M14×1.25 90 9.0
L: apply thread fastening glue.
R: replace parts.
Si: apply silicone grease.
- 283 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
