Benelli TNT125 Service Manual

N
o. Chinese name and specification Torque Remark
N·m kgf·m
1 Inner hexagon screw M8×1.25×25 25
2.5
2 Upper seat of handlebar
3 Lower handle positioned
4 Damper
5 Double end stud for positioning of handle 25
2.5 L
6 Upper bracket clamp screw 50
5.0
7 Upper bracket
8 Handle positioning washer
9 Self-locking nut M10×1.25 40
4.0
10 Upper bracket clamping nut 25
2.5
11 Gland nut 25
2.5
12 Dust seal
13 Steering bearing
R、G
14 Steering column
15 Lock ring
R
16 Lower bracket
17 Front left shock absorber component
18 Front right shock absorber component
19 Screw M6×14 10
1.0
20 Bolt M6×65 10
1.0
21 Clamp of hydraulic brake pipe
22 Cushion shaft sleeve of headlight
23 Mounting washer bush under headlight
24 Mounting palte below headlight
25 Clutch clamp component
26 Self-locking nut M6 10
1.0
27 Lower bracket clamp component
G: apply grease
L: apply thread fastening glue
R: replace parts
- 339 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
