●Install the fixing tool [A], as shown in the figure
Remark
○
The upper part protecting device [B] shall not
touch the inner pipe when installing the fixing tool;
pull up the outer pipe [C], clamp the outer pipe with
the tool, and then lock the two bolts [D]. The outer
pipe plays a guiding role.
●
After the spring is pressed with the special tool
,
di
sassemble the front shock absorber bolt [A] and nut
[B] with a wrench
- 345 -
