Benelli TNT125 Service Manual

No. Chinese name and specification
Torque
Remark
N·m kgf·m
1
Internal hexagon screw M6x35
10
1.0
2
Counterbalance
3
Counterbalance installing seat
10
1.0
4
Right grip component
5
Right combination switch
6
Right rearview mirror component
7
Throttle cable component
8
Handlebar
9
Left rearview mirror component
10
Left combination switch
11
Left handlebar grip
12
Clutch handle component
13
Clutch cable jacket
14
Clutch cable component
15
Nut M6
10
1.0
16
Internal hexagon screw M5x14
6
0.6
17
Adjusting solenoid
18
Slotted nut
19
Clutch switch
20
Left handle seat afterbody
21
Left handle seat screw
22
Left handle
23
Nut M6
10
1.0
AD: apply adhesive.
AL: lock the two clamp bolts twice alternately to ensure that the locking torque is even.
G: apply grease.
L: apply thread fastening glue.
R: spare parts
- 357 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
