The Control List
Manpack Transceiver 2110 series Reference Manual 239
RS232 Mode
(2110 only)
Set the mode in which the RS232 19-way serial port operates.
If the port is:
• not in use, select None
• receiving GPS information from an external GPS receiver,
select GPS
• controlling and monitoring the transceiver, select CICS
• connected to a 9001/3012 modem, select Fax/Data
• connected to a radio/telephone interconnect unit, select
3033/RTU–292
• connected to a single-tone low-rate FSK Pactor modem, select
Pactor 1
• connected to a multi-tone/PSK HAL or Clover modem, select
HAL/Clover
• connected to a multi-tone modem, select Modem Slow AGC
• connected to a non-Codan modem located in an area that is
prone to frequent lightning strikes, select Modem Fast AGC
(this may improve the performance)
• connected to a VP-116 Voice Privacy Unit, select VP-116
None
RS232 Speed Set the data rate of the RS232 19-way serial port. 9600
RS232 Startup
(2110 only)
Set the serial commands you want to have performed by the
19-way port following power on, for example, setting the self
address that is used by CICS during transmissions, echo off etc.
For more information see page 265, RS232 Startup entry.
Scan Switch scanning on or off.
Scan Allow Enable or disable scanning. Yes
Screen Auto-Dim Set the time the transceiver waits after a key is pressed before
switching off the backlighting on the front panel screen. The
backlighting is automatically switched on again when a key is
pressed.
1 minute
Screen Brightness Set the brightness of the screen.
Screen Contrast Set the contrast of the screen.
Screen Scroll Rate Set the speed with which characters on the screen scroll when the
line length exceeds the screen width.
0.8 seconds
Screen Scroll Step Set the number of characters on the screen that scroll as a block
when the line length exceeds the screen width.
2
Secure Index Select the Corporate secure index.
Secure Key Set the CES secure key or AES secure key for a particular secure
index.
Table 31: Entries in the Control List (cont.)
Name of entry Use this entry to... Default
