The Control List

254 Manpack Transceiver 2110 series Reference Manual

Displaying the options installed in your transceiver

The transceiver provides a summary of the firmware and hardware options installed in

your transceiver.

To view the list of options in the transceiver:

1 Press until Main Menu is displayed.

1 Scroll to Control, then press .

1 Scroll to Devices, then press .

1 Scroll to Tcvr features, then press .

The list of options that are fitted and enabled in the transceiver is displayed.

Any of the following options may be displayed:

• AES-256 Voice

• AES-256 RM50 <firmware version>[ ]

• CES-128 Voice

• Internal Voice

• Private Voice

• FED-STD-1045 ALE

• MIL-STD-188-141B ALE

• GPS options

• Internal GPS

• Amateur Mode

• Filter 2

• TxD or TxP or TxE

• Max Pwr <nn> W
