Error Codes and Suggested Resolutions

Service Manual B-3

005

Category: A/D

Alarm Priority: Low

Description: Temperature > 48°C for at least 30 consecutive seconds.

Resolution: Replace the power PCBA. See page 10-31.

006

Category: A/D

Alarm Priority: Medium

Description: Thermal cut-out switch has opened.

Resolution: Check for:

• Thermistor dislodged from hose duct adapter - See page 11-3.

If the thermistor is in position, replace the power PCBA. See page 10-31.

Note: This error is also generated during the thermostat test as part of perfor-

mance verification.

011

Category: A/D

Alarm Priority: Medium

Description: Thermistor temperature too low to measure.

Resolution: Replace the thermistor. See page 11-3.

012

Category: A/D

Alarm Priority: Medium

Description: Thermistor temperature too high to measure.

Resolution: Replace the thermistor. See page 11-3.
