Covidien WarmTouch

To Next Page

To Previous Page

Error Codes

B-4 Service Manual

013

Category: A/D

Alarm Priority: Low

Description: Fan motor drew too much current.

Resolution: Check for:

• Blockage in fan - See page 11-33.

If there is no blockage, replace the fan. See page 11-33.

If this does not resolve the issue, replace the power PCBA. See page 10-31.

014

Category: A/D

Alarm Priority: Low

Description: Fan speed < 3000 rpm.

Resolution: Check for:

• Blockage in fan - See page 11-33.

If there is no blockage, replace the fan. See page 11-33.

If this does not resolve the issue, replace the power PCBA. See page 10-31.

015

Category: A/D

Alarm Priority: Low

Description: Fan speed > 5000 rpm.

Resolution: Replace the power PCBA. See page 10-31.
