Error Codes and Suggested Resolutions

Service Manual B-5

016

Category: A/D

Alarm Priority: Low

Description: Fan speed too low for current fan voltage.

Resolution: Check for:

• Blockage in fan - See page 11-33.

If there is no blockage, replace the fan. See page 11-33.

017

Category: A/D

Alarm Priority: Low

Description: Fan speed too high for current fan voltage.

Resolution: Replace the fan. See page 11-33.

028

Category: A/D

Alarm Priority: Low

Description: Flash erase error during software upgrade.

Resolution: Replace the power PCBA. See page 10-31.

029

Category: A/D

Alarm Priority: Low

Description: Flash write error during software upgrade.

Resolution: Replace the power PCBA. See page 10-31.
