Error Codes

B-6 Service Manual

030

Category: A/D

Alarm Priority: Low

Description: Flash verify error during software upgrade.

Resolution: Replace the power PCBA. See page 10-31.

031

Category: A/D

Alarm Priority: Low

Description: Invalid flash state (software error) during software upgrade.

Resolution: Replace the power PCBA. See page 10-31.

032

Category: A/D

Alarm Priority: Low

Description: Checksum error on downloaded software during software upgrade.

Resolution: Try reloading the software. See page 7-7.

If this does not resolve the issue, either the A/D or UI microprocessor could be at

fault. First, try replacing the power PCBA. See page 10-31. If the problem persists,

try replacing the UI PCBA. See page 10-12.

033

Category: A/D

Alarm Priority: Low

Description: Timeout on A/D SW update data message during software upgrade.

Resolution: Check for:

• Disconnected USB cable.

Try reloading the software. See page 7-7.
