Command table (Continued) D
Remote jack (CI-V) information
Cmd. Sub cmd. Data Description
14 0E 0000 to
0255
Send/read the COMP level
(0000=0 to 0255=10)
0F 0000 to
0255
Send/read the Break-IN Delay
setting
(0000=2.0d to 0255=13.0d)
12 0000 to
0255
Send/read NB level
(0000=0% to 0255=100%)
15 0000 to
0255
Send/read the Monitor gain level
(0000=0% to 0255=100%)
16 0000 to
0255
Send/read the VOX gain level
(0000=0% to 0255=100%)
17 0000 to
0255
Send/read the Anti VOX gain level
(0000=0% to 0255=100%)
18 0000 to
0255
Send/read the LCD contrast level
(0000=0% to 0255=100%)
19 0000 to
0255
Send/read the LCD backlight level
(0000=0% to 0255=100%)
15 01 00 Read the squelch status
(squelch closed)
01 Read the squelch status
(squelch open)
02 0000 to
0255
Read the S-meter level
( 0000=S0, 0120=S9, 0241=S9+60
dB)
05 00 Read various SQL function’s status
(squelch closed)
01 Read various SQL function’s status
(squelch open)
11 0000 to
0255
Read the PO meter level
(0000=0%, 0143=50%, 213=100%)
12 0000 to
0255
Read the SWR meter level
(0000=SWR1.0, 0048=SWR1.5,
0080=SWR2.0, 0120=SWR3.0)
13 0000 to
0255
Read the ALC meter level
(0000=Min. to 0120=Max.)
14 0000 to
0255
Read the COMP meter level
( 0000=0 dB, 0130=15 dB,
0241=30 dB)
15 0000 to
0255
Read the Vd meter level
(0000=0 V, 0013=10 V, 0241=16 V)
16 0000 to
0255
Read the Id meter level
( 0000=0, 0097=10, 0146=15,
0241=25)
16 02 00 Send/read Preamp OFF
01 Send/read Preamp ON
(144/430 MHz)
Send/read Preamp 1 ON
(HF/50 MHz)
02 Send/read Preamp 2 ON
(HF/50 MHz)
12 01 Send/read AGC FAST
02 Send/read AGC MID
03 Send/read AGC SLOW
22 00 Send/read Noise Blanker OFF
01 Send/read Noise Blanker ON
40 00 Send/read Noise Reduction OFF
01 Send/read Noise Reduction ON
41 00 Send/read Auto Notch function OFF
01 Send/read Auto Notch function ON
42 00 Send/read Repeater tone OFF
01 Send/read Repeater tone ON
43 00 Send/read Tone squelch OFF
01 Send/read Tone squelch ON
Cmd. Sub cmd. Data Description
16 44 00 Send/read Speech compressor
OFF
01 Send/read Speech compressor ON
45 00 Send/read Monitor function OFF
01 Send/read Monitor function ON
46 00 Send/read VOX function OFF
01 Send/read VOX function ON
47 00 Send/read BK-IN function OFF
01 Send/read Semi BK-IN function ON
02 Send/read Full BK-IN function ON
48 00 Send/read Manual notch function
OFF
01 Send/read Manual notch function
ON
4B 00 Send/read DTCS OFF
01 Send/read DTCS ON
4C 00 Send/read VSC function OFF
01 Send/read VSC function ON
4F 00 Send/read Twin Peak Filter OFF
01 Send/read Twin Peak Filter ON
50 00 Send/read Dial lock function OFF
01 Send/read Dial lock function ON
56 00 Send/read DSP filter type SHARP
01 Send/read DSP filter type SOFT
57 00 Send/read manual notch width
WIDE
01 Send/read manual notch width MID
02 Send/read manual notch width NAR
58 00 Send/read SSB transmit bandwidth
WIDE
01 Send/read SSB transmit bandwidth
MID
02 Send/read SSB transmit bandwidth
NAR
5B 00 Send/read DSQL/CSQL OFF
(DV mode only)
01 Send/read DSQL ON
(DV mode only)
02 Send/read CSQL ON
(DV mode only)
17 see p. 20-11 Send CW messages*
1
18 00 Turn OFF the transceiver
01 Turn ON the transceiver*
2
*
1
In the CW mode, if an external TX switch is ON, or the Break-in func-
tion is ON, a message will be transmitted as CW code when you send
it from your PC.
*
2
When sending the power ON command (18 01), the command “FE”
must be sent before the basic format.
• 19200 bps: 25, • 9600 bps: 13, • 4800 bps: 7,
• 1200 bps: 3, • 300 bps: 2
qwert
u
F
F E
× 7
88EFEE 1081ODF
Example: When operating with 4800 bps
q Preamble code (fixed)
w Transceiver’s default address
e Controller’s default address
r Command number
t Sub command number
u End of message code (fixed)
Previous view
