20
CONTROL COMMAND
20-5
Command table (Continued) D
Remote jack (CI-V) information
Cmd. Sub cmd. Data Description
19 00 Read the transceiver ID
1A 00 see p. 20-16 Send/read the Memory channel
contents
01 see p. 20-12 Send/read the Band stacking regis-
ter contents
02 see p. 20-13 Send/read the Memory keyer
contents*
03 00 to 49 Send/read the selected filter width
( AM: 00=200 Hz to 49=10 kHz;
other than AM modes: 00=50 Hz to
40/31=3600 Hz/2700 Hz)
04 00 to 13 Send/read the selected AGC time
constant
( 00=OFF, AM: 01=0.3 sec. to
13=8.0 sec., SSB/CW/RTTY:
01=0.1 sec. to 13=6.0 sec.)
05 0001 00/01 Send/read the TX Monitor function
setting
(00=OFF, 01=ON)
0002 0000 to
0255
Send/read the TX Monitor level
(0000=0% to 0255=100%)
0003 Send/read the Beep level
(0000=0% to 0255=100%)
0004 00/01 Send/read the Beep level limit
setting
(00=OFF, 01=ON)
0005 00/01 Send/read the Confirmation beep
setting
(00=OFF, 01=ON)
0006 00 to 03 Send/read the Band edge beep
setting
( 00=OFF, 01=ON(Default),
02=ON(User),
03=ON(User & TX Limit))
0007 00 to 02 Send/read the RF/SQL Control
setting
(00=Auto, 01=SQL, 02=RF+SQL)
0008 00 to 05 Send/read the TX Delay setting
(HF)
( 00=OFF, 01=10ms, 02=15ms,
03=20ms, 04=25ms, 05=30ms)
0009 00 to 05 Send/read the TX Delay setting
(50M)
( 00=OFF, 01=10ms, 02=15ms,
03=20ms, 04=25ms, 05=30ms)
0010 00 to 05 Send/read the TX Delay setting
(70M)
( 00=OFF, 01=10ms, 02=15ms,
03=20ms, 04=25ms, 05=30ms)
0011 00 to 05 Send/read the TX Delay setting
(144M)
( 00=OFF, 01=10ms, 02=15ms,
03=20ms, 04=25ms, 05=30ms)
0012 00 to 05 Send/read the TX Delay setting
(430M)
( 00=OFF, 01=10ms, 02=15ms,
03=20ms, 04=25ms, 05=30ms)
0013 00 to 05 Send/read the Time-Out Timer
setting
( 0=OFF, 1=3 min., 2=5 min., 3=10
min., 4=20 min., 5=30 min.)
0014 00/01 Send/read the PTT Lock function
setting
(00=OFF, 01=ON)
Cmd. Sub cmd. Data Description
1A 05 0015 00/01 Send/read the Quick Split function
setting
(00=OFF, 01=ON)
0016 see p. 20-13 Send/read the Split offset frequency
0017 00/01 Send/read the Split Lock function
setting
(00=OFF, 01=ON)
0018 see p. 20-13 Send/read the Duplex offset fre-
quency
0019 00/01 Send/read the One Touch Repeater
setting
(00=DUP-, 01=DUP+)
0020 00 to 02 Send/read the Auto Repeater set-
ting
( 0=OFF, 1=ON(DUP) (for USA
version) or ON (for Korea ver-
sion), 2=ON(DUP,TONE)(for USA
version)
0021 00/01 Send/read the Tuner Auto Start
setting
(00=OFF, 01=ON)
0022 00/01 Send/read the PTT Tune setting
(00=OFF, 01=ON)
0023 00 Send/read the Manual selection for
the [TUNER] Switch function.
01 Send/read the Auto selection for the
[TUNER] Switch function.
0024 00/01 Send/read [SPEECH/LOCK] key
function setting
( 00=Push: SPEECH, Hold down:
LOCK), 01=Push: LOCK, Hold
down: SPEECH)
0025 00/01 Send/read the Lock function setting
(00=MAIN DIAL, 01=PANEL)
0026 00/01 Send/read the number of memo
pad channels
(00=5CH, 01=10CH)
0027 00 to 02 Send/read the Auto TS setting for
the Dial
(00=OFF, 01=LOW, 02=HIGH)
0028 00/01 Send/read the microphone Up/
Down speed setting
(00=Slow, 01=Fast)
0029 00 to 02 Send/read the Notch function set-
ting for SSB mode
( 00=Auto, 01=Manual,
02=Auto/Manual)
0030 00 to 02 Send/read the Notch function set-
ting for AM mode
( 00=Auto, 01=Manual,
02=Auto/Manual)
0031 00/01 Send/read the SSB/CW Synchro-
nous Tuning function setting
(00=OFF, 01=ON)
0032 00/01 Send/read the CW normal side
setting
(00=LSB, 01=USB)
0033 00/01 Send/read the voice 1st menu
(00=VOICE-Root, 01=VOICE-TX)
0034 00/01 Send/read the keyer 1st menu
( 00=KEYER-Root,
01=KEYER-SEND)
*
The counter can be inserted into only one channel. Before inserting the
counter, be sure to clear the counter on another channel.
