20
CONTROL COMMAND
20-12
• Character code setting
Command: 1A 00, 1A 05 0200, 1A 05 0201,
1A 05 0206, 1A 05 0207, 1A 05 0208,
1A 05 0209, 1A 05 0211, 1F 02, 20 0001,
20 0002
Character ASCII code Character ASCII code
A–Z 41–5A a–z 61–7A
0–9 30–39 Space 20
! 21 # 23
$ 24 % 25
& 26 \ 5C
? 3F " 22
’ 27 ` 60
^ 5E + 2B
– 2D
✱
2A
⁄ 2F . 2E
, 2C : 3A
; 3B = 3D
< 3C > 3E
(
28
)
29
[
5B
]
5D
{
7B
}
7D
¦ 7C
_
5F
¯ 7E @ 40
• Band edge frequency setting
Command 02*, 1E 01, 1E 03
q
XXX
w ertyuio!0!1!2
XXXXXXXXX2DXXXXXXXXXX
10 Hz digit: 0–9
1 Hz digit: 0–9
1 kHz digit: 0–9
100 Hz digit: 0–9
100 kHz digit: 0–9
10 kHz digit: 0–9
10 MHz digit: 0–9
1 MHz digit: 0–9
1000 MHz digit: 0 (fixed)
100 MHz digit: 0–9
10 Hz digit: 0–9
1 Hz digit: 0–9
1 kHz digit: 0–9
100 Hz digit: 0–9
100 kHz digit: 0–9
10 kHz digit: 0–9
10 MHz digit: 0–9
1 MHz digit: 0–9
1000 MHz digit: 0 (fixed)
100 MHz digit: 0–9
Separator (fixed)
Lower edge Higher edge
Edge number*: 01–30
* Edge number (q) is not sent with command 02 (reading the
band edge frequencies).
• Band stacking register
Command : 1A 01
When sending the contents, the codes, such as op-
erating frequency and operating mode*, should be
added after the frequency band code and register
code, as shown below.
* See t to %1 on ‘Memory content setting.’ (p. 20-16)
Frequency band code q
Code Freq. band Frequency range (unit: MHz)
01 1.8 1.800000– 1.999999
02 3.5 3.400000– 4.099999
03 7 6.900000– 7.499999
04 10 9.900000–10.499999
05 14 13.900000–14.499999
06 18 17.900000–18.499999
07 21 20.900000–21.499999
08 24 24.400000–25.099999
09 28 28.000000–29.999999
10 50 50.000000–54.000000
11 144 144.000000–148.000000
12 430 420.000000–450.000000
13 GENE Other than above
Register code w
Code Registered No.
01 1 (latest)
02 2
03 3 (oldest)
To read the contents, the register code should be add-
ed after the frequency band code, as shown below.
Example: When reading the oldest contents in the
21 MHz band, the code “0703” is used.
Data content description (Continued) D
Remote jack (CI-V) information
