Icom IC-7100

20
CONTROL COMMAND
20-13
• Memory keyer contents
Command: 1A 02
X
q: Channel data
w–&1: Text data
XXX
……
XX
01：M1
02：M2
03：M3
04：M4
• Character’s code
Character ASCII code Description
0–9 30–39 Number
A–Z 41–5A Alphabetical characters
a–z 61–7A Alphabetical characters
space 20 Word space
/ 2F Symbol
? 3F Symbol
, 2C Symbol
. 2E Symbol
@ 40 Symbol
^ 5E
e.g., to send BT, enter ^BT
✱
2A Inserts contest number (can be
used for 1 channel only)
• Split offset frequency setting
Command: 1A 05 0016
1 kHz digit: 0–9 100 Hz digit: 0 (fixed) 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0 (fixed) 1 MHz digit: 0–9 Direction: 00: + direction 01: – direction
q
0XXXXXX
we
0
r
• Duplex Offset frequency setting
Command: 1A 05 0018
q
XXXXX
we
X
1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0 (fixed) 1 MHz digit: 0–9
• UTC Offset setting
Command: 1A 05 0123
q
XXXX
we
XX
10 hour digit: 0–1 1 hour digit: 0–9 10 min. digit: 0–5 1 min. digit: 0–9 Direction 00=+ direction 01=– direction
• My position data setting
Command: 1A 05 0186
q
XXXXXXX00X0XXXXXXXX00XXXXXXX0X
wertyuio!0 !1 !4
†
!5
†
!3
†
!2
†
Latitude AltitudeLongitude
10 degree digit: 0–9 1 degree digit: 0–9 10 min. digit: 0–5 1 min. digit: 0–9 0.1 min. digit: 0–9 0.01 min. digit: 0–9 0.001 min. digit: 0–9 0 (fixed) 0 (fixed) S*=0/N*=1 0 (fixed) 100 degree digit: 0–1 10 degree digit: 0–9 1 degree digit: 0–9 10 min. digit: 0–5 1 min. digit: 0–9 0.1 min. digit: 0–9 0.01 min. digit: 0–9 0.001 min. digit: 0–9 0 (fixed) 0 (fixed) W*=0/E*=1 10000 meter digit: 0–1 1000 meter digit: 0–9 100 meter digit: 0–9 10 meter digit: 0–9 1 meter digit: 0–9 0.1 meter digit: 0–9 0 (fixed) +=0/−=1
* S: South latitude N: North latitude
W: West longitude E: East longitude
†
When reading the contents with no altitude, sends !2, !3, !4
and !5 as “FF.”
When sending the contents with no altitude, set !2, !3, !4
and !5 to “FF.”
• Alarm area (Group) setting
Command: 1A 05 0191
q
XXXX0
we
0
10 min. digit: 0–5 1 min. digit: 0–9 0.1 min. digit: 0–9 0.01 min. digit: 0–9 0.001 min. digit: 0–9 0 (fixed)
• Unproto Address setting
Command: 1A 05 0201
Set an unproto address of up to 56 characters.
See ‘Character code setting.’ (p. 20-12)
Data content description (Continued) D
