Intel Arria 10 User Manual

Signal Name Direction Clock Domain Description
led_panel_link
Output Synchronous to
mgmt_clk
When asserted, this signal indicates the following
behavior:
Mode Behavior
1000 Base-X without Auto-
negotiation
When asserted, indicates
successful link
synchronization.
SGMII mode without Auto-
negotiation
When asserted, indicates
successful link
synchronization.
1000 Base-X with Auto-
negotiation
Clause 37 Auto-negotiation
status. The PCS function
asserts this signal when
auto-negotiation completes.
SGMII mode with MAC
mode Auto-negotiation
Clause 37 Auto-negotiation
status. The PCS function
asserts this signal when
auto-negotiation completes.
rx_block_lock
Output Synchronous to
rx_clkout
Asserted to indicate that the block synchronizer has
established synchronization.
rx_hi_ber
Output Synchronous to
rx_clkout
Asserted by the BER monitor block to indicate a Sync
Header high bit error rate greater than 10
-4
.
rx_is_lockedtodat
a
Output Asynchronous signal When asserted, indicates the RX channel is locked to input
data.
tx_cal_busy
Output Synchronous to
mgmt_clk
When asserted, indicates that the TX channel is being
calibrated.
rx_cal_busy
Output Synchronous to
mgmt_clk
When asserted, indicates that the RX channel is being
calibrated.
tx_pcfifo_error_1
g
Output N/A When asserted, indicates that the standard PCS TX phase
compensation FIFO is either full or empty.
rx_pcfifo_error_1
g
Output N/A When asserted, indicates that the Standard PCS RX phase
compensation FIFO is either full or empty.
lcl_rf
Input Synchronous to
xgmii_tx_clk
When asserted, indicates a Remote Fault (RF).The MAC
sends this fault signal to its link partner. Bit D13 of the
Auto Negotiation Advanced Remote Fault register
(0xC2) records this error.
rx_clkslip
Input Asynchronous signal When asserted, the deserializer either skips one serial bit
or pauses the serial clock for one cycle to achieve word
alignment. As a result, the period of the parallel clock
could be extended by 1 unit interval (UI) during the clock
slip operation.This is an optional control input signal.
rx_data_ready
Output Synchronous to
xgmii_rx_clk
When asserted, indicates that the MAC can begin sending
data to the PHY.
rx_latency_adj_10
g[15:0]
Output Synchronous to
xgmii_rx_clk
When you enable 1588, this signal outputs the real time
latency in XGMII clock cycles (156.25 MHz) for the RX
PCS and PMA datapath for 10G mode. Bits 0 to 9
represent the fractional number of clock cycles. Bits 10 to
15 represent the number of clock cycles.
continued...
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
147

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
