Addr Bit Access Name Description
0x482 1 RO
HI_BER
High BER status. When set to 1, the PCS reports a high
BER. When set to 0, the PCS does not report a high
BER.
2 RO
BLOCK_LOCK
Block lock status. When set to 1, the PCS is locked to
received blocks. When set to 0, the PCS is not locked to
received blocks.
3 RO
TX_FIFO_FULL When set to 1, the TX_FIFO is full.
4 RO
RX_FIFO_FULL When set to 1, the RX_FIFO is full.
7 RO
Rx_DATA_READY
When set to 1, indicates the PHY is ready to receive
data.
2.6.3.6.4. PMA Registers
The PMA registers allow you to reset the PMA, customize the TX and RX serial data
interface, and provide status information.
Table 125. 1G Data Mode
Addr Bit R/W Name Description
0x4A8 0 RW
tx_invpolarity
When set, the TX interface inverts the polarity of
the TX data to the 8B/10B encoder.
1 RW
rx_invpolarity
When set, the RX channels inverts the polarity of
the received data to the 8B/10B decoder.
2 RW
rx_bitreversal_enable
When set, enables bit reversal on the RX interface
to the word aligner.
3 RW
rx_bytereversal_enable
When set, enables byte reversal on the RX interface
to the byte deserializer.
4 RW
force_electrical_idle
When set, forces the TX outputs to electrical idle.
0x4A9 0 R
rx_syncstatus
When set, the word aligner is synchronized.
1 R
rx_patterndetect
GbE word aligner detected comma.
2 R
rx_rlv
Run length violation.
3 R
rx_rmfifodatainserted
Rate match FIFO inserted code group.
4 R
rx_rmfifodatadeleted
Rate match FIFO deleted code group.
5 R
rx_disperr
RX 8B10B disparity error.
6 R
rx_errdetect
RX 8B10B error detected.
Table 126. PMA Registers
Address Bit R/W Name Description
0x444 1 RW
reset_tx_digital
Writing a 1 asserts the internal TX digital reset signal. You
must write a 0 to clear the reset condition.
2 RW
reset_rx_analog
Writing a 1 causes the internal RX analog reset signal to be
asserted. You must write a 0 to clear the reset condition.
3 RW
reset_rx_digital
Writing a 1 causes the internal RX digital reset signal to be
asserted. You must write a 0 to clear the reset condition.
0x461 0 RW
phy_serial_loopback
Writing a 1 puts the channel in serial loopback mode.
continued...
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
161
