Intel Arria 10 User Manual

Word
Addr
Bit R/W Name Description
13 RW
LT VODMin ovrd
Enable
When set to 1, enables the override value for the
VODMINRULE parameter stored in the LT VODMin ovrd
register field.
21:16 RW
LT VPOST ovrd
Override value for the VPOSTRULE parameter. When
enabled, this value substitutes for the VPOSTRULE to allow
channel-by-channel override of the device settings. This
override only effects the local device TX output for this
channel.
The value to be substituted must be greater than the
INITPOSTVAL parameter for proper operation.
22 RW
LT VPOST ovrd Enable
When set to 1, enables the override value for the
VPOSTRULE parameter stored in the LT VPOST ovrd
register field.
28:24 RW
LT VPre ovrd
Override value for the VPRERULE parameter. When enabled,
this value substitutes for the VPOSTRULE to allow channel-
by-channel override of the device settings. This override only
effects the local device TX output for this channel.
The value to be substituted must be greater than the
INITPREVAL parameter for proper operation.
29 RW
LT VPre ovrd Enable
When set to 1, enables the override value for the VPRERULE
parameter stored in the LT VPre ovrd register field.
0x4D7
to 0x4FF
Reserved for 40G KR Left empty for address compatibility with 40G MAC+PHY KR
solution.
2.6.3.6.2. Hard Transceiver PHY Registers
Table 123. Hard Transceiver PHY Registers
Addr Bit Access Name Description
0x000-0
x3FF
[9:0] RW Access to HSSI
registers
All registers in the physical coding sub-layer (PCS) and physical
media attachment (PMA) that you can dynamically reconfigure
are in this address space. Refer to the Arria 10 Dynamic
Transceiver Reconfiguration chapter for further information.
Related Information
Reconfiguration Interface and Dynamic Reconfiguration on page 502
2.6.3.6.3. Enhanced PCS Registers
Table 124. Enhanced PCS Registers
Addr Bit Access Name Description
0x480 31:0 RW
Indirect_addr
Because the PHY implements a single channel, this
register must remain at the default value of 0 to specify
logical channel 0.
0x481 2 RW
RCLR_ERRBLK_CNT
Error block counter clear register. When set to 1, clears
the RCLR_ERRBLK_CNT register. When set to 0, normal
operation continues.
3 RW
RCLR_BER_COUNT
BER counter clear register. When set to 1, clears the
RCLR_BER_COUNT register. When set to 0, normal
operation continues.
continued...
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
160

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
