Signal Name Direction Clock Domain Description
• Turn on Enable internal PCS reconfiguration logic
start_pcs_reconf
ig
Input Synchronous to
mgmt_clk
When asserted, initiates reconfiguration of the PCS.
Sampled with the mgmt_clk. This signal is only exposed
under the following condition:
• Turn on Enable internal PCS reconfiguration logic
mode_1g_10gbar
Input Synchronous to
mgmt_clk
This signal selects either the 1G or 10G tx-parallel-data
going to the PCS. It is only used for the 1G/10G
application (variant) under the following circumstances:
• the Sequencer (auto-rate detect) is not enabled
• 1G mode is enabled
2.6.4.7. Avalon-MM Register Interface
The Avalon-MM slave interface signals provide access to all registers.
Table 144. Avalon-MM Interface Signals
Signal Name Direction Clock Domain Description
mgmt_clk
Input Clock The clock signal that controls the Avalon-MM PHY management
interface. If you plan to use the same clock for the PHY
management interface and transceiver reconfiguration, you must
restrict the frequency to 100-125 MHz to meet the specification
for the transceiver reconfiguration clock.
mgmt_clk_res
et
Input Asynchronous reset Resets the PHY management interface. This signal is active high
and level sensitive.
mgmt_addr[10
:0]
Input Synchronous to
mgmt_clk
11-bit Avalon-MM address.
mgmt_writeda
ta[31:0]
Input Synchronous to
mgmt_clk
Input data.
mgmt_readdat
a[31:0]
Output Synchronous to
mgmt_clk
Output data.
mgmt_write
Input Synchronous to
mgmt_clk
Write signal. Active high.
mgmt_read
Input Synchronous to
mgmt_clk
Read signal. Active high.
mgmt_waitreq
uest
Output Synchronous to
mgmt_clk
When asserted, indicates that the Avalon-MM slave interface is
unable to respond to a read or write request. When asserted,
control signals to the Avalon-MM slave interface must remain
constant.
Related Information
Avalon Interface Specifications
2.6.4.7.1. 1G/10GbE Register Definitions
The Avalon-MM master interface signals provide access to the control and status
registers.
The following table specifies the control and status registers that you can access over
the Avalon-MM interface. A single address space provides access to all registers.
Note:
Unless otherwise indicated, the default value of all registers is 0.
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
181
