Parameter Gen1 PIPE Gen2 PIPE Gen3 PIPE (For Gen1/
Gen2 speeds)
Number of auxiliary MCGB
clock input ports
N/A for x1
0 for x2, x4, x8
N/A for x1
0 for x2, x4, x8
N/A for x1
N/A for x2, x4, x8
MCGB input clock frequency 1250MHz 2500MHz 2500MHz
MCGB output data rate 2500Mbps 5000Mbps 5000Mbps
Bonding
Enable bonding clock output
ports
N/A for x1 design
Enable for x2, x4, x8
N/A for x1 design
Enable for x2, x4, x8
N/A for x1
N/A for x2, x4, x8
Enable feedback
compensation bonding
N/A for x1 design
Disable for x2, x4, x8
N/A for x1 design
Disable for x2, x4, x8
N/A for x1
N/A for x2, x4, x8
PMA interface width N/A for x1 design
10 for x2, x4, x8
N/A for x1 design
10 for x2, x4, x8
N/A for x1
N/A for x2, x4, x8
Dynamic Reconfiguration
Enable dynamic
reconfiguration
Disable Disable Disable
Enable Altera Debug Master
Endpoint
Disable Disable Disable
Separate avmm_busy from
reconfig_waitrequest
N/A N/A N/A
Optional Reconfiguration Logic
Enable capability registers N/A N/A N/A
Set user-defined IP identifier N/A N/A N/A
Enable control and status
registers
N/A N/A N/A
Configuration Files
Configuration file prefix N/A N/A N/A
Generate SystemVerilog
package file
N/A N/A N/A
Generate C Header file N/A N/A N/A
Generate MIF (Memory
Initialize file)
N/A N/A N/A
Generation Options
Generate parameter
documentation file
Enable Enable Enable
Related Information
Using the Arria 10 Transceiver Native PHY IP Core on page 45
2. Implementing Protocols in Arria 10 Transceivers
