Parameter Gen1 PIPE Gen2 PIPE Gen3 PIPE (For Gen3
speed)
Number of auxiliary MCGB clock input
ports
N/A for x1
0 for x2, x4, x8
N/A for x1
0 for x2, x4, x8
N/A for x1
1 for x2, x4, x8
MCGB input clock frequency 1250 MHz 2500 MHz 4000 MHz
MCGB output data rate 2500 Mbps 5000 Mbps 8000 Mbps
Bonding
Enable bonding clock output ports N/A for x1
Enable for x2, x4, x8
N/A for x1
Enable for x2, x4, x8
N/A for x1
Enable for x2, x4, x8
Enable feedback compensation bonding N/A for x1 design
Disable for x2, x4, x8
N/A for x1 design
Disable for x2, x4, x8
Disable for x1
Disable for x2, x4, x8
PMA interface width N/A for x1 design
10 for x2, x4, x8
N/A for x1 design
10 for x2, x4, x8
N/A for x1
10 for x2, x4, x8
Dynamic Reconfiguration
Enable dynamic reconfiguration Disable Disable Disable
Enable Altera Debug Master Endpoint Disable Disable Disable
Separate avmm_busy from
reconfig_waitrequest
N/A N/A N/A
Optional Reconfiguration Logic
Enable capability registers N/A N/A N/A
Set user-defined IP identifier N/A N/A N/A
Enable control and status registers N/A N/A N/A
Configuration Files
Configuration file prefix N/A N/A N/A
Generate SystemVerilog package file N/A N/A N/A
Generate C Header file N/A N/A N/A
Generate MIF (Memory Initialize file) N/A N/A N/A
Generation Options
Generate parameter documentation file Enable Enable Enable
Related Information
Using the Arria 10 Transceiver Native PHY IP Core on page 45
