Intel Arria 10 User Manual

Document
Version
Changes
• Updated figure "Arria 10 SX Device with 48,36, and 24 Transceiver Channels and Two PCIe Hard IP
Blocks.
• Updated figure "Arria 10 SX Devices with Six Transceiver Channels and One PCIe Hard IP Block" to
add a clarification about PCIe Hard IP.
• Updated the device package names in Table 1-5 in "Arria 10 SX Device Package Details" section.
• Removed all references of the note about PCS-Direct support available in future release.
2013.12.02 Initial release.
1. Arria
®
10 Transceiver PHY Overview
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
31

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
