Document
Version
Changes
Updated the "Transmitter Reset Sequence After Power-Up" and "Receiver Reset Sequence Following
Power-Up" figures.
Updated the "Resetting the Receiver During Device Operation" procedure and associated figure.
Updated the "Reset Sequence Timing Diagram for Transceiver when CDR is in Manual Lock Mode"
figure.
2013.12.02 Initial release.
4. Resetting Transceiver Channels
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
446
