The rx_syncstatus and rx_patterndetect signals, with the same latency as the
datapath, are forwarded to the FPGA fabric to indicate the word aligner status.
After receiving the first word alignment pattern after rx_std_wa_patternalign is
asserted, both rx_syncstatus and rx_patterndetect are driven high for one
parallel clock cycle. Any word alignment pattern received thereafter in the same word
boundary causes only rx_patterndetect to go high for one clock cycle. Any word
alignment pattern received thereafter in a different word boundary causes the word
aligner to re-align to the new word boundary only if rx_std_wa_patternalign is
asserted. The word aligner asserts rx_syncstatus for one parallel clock cycle
whenever it re-aligns to the new word boundary.
5.3.2.1.3. Word Aligner Synchronous State Machine Mode
In synchronous state machine mode, when the programmed number of valid
synchronization code groups or ordered sets is received, rx_syncstatus is driven
high to indicate that synchronization is acquired. The rx_syncstatus signal is
constantly driven high until the programmed number of erroneous code groups is
received without receiving intermediate good groups, after which rx_syncstatus is
driven low.
The word aligner indicates loss of synchronization (rx_syncstatus remains low)
until the programmed number of valid synchronization code groups are received
again.
5.3.2.1.4. Word Aligner Deterministic Latency Mode
In deterministic latency mode, the state machine removes the bit level latency
uncertainty. The deserializer of the PMA creates the bit level latency uncertainty as it
comes out of reset.
The PCS performs pattern detection on the incoming data from the PMA. The PCS
aligns the data, after it indicates to the PMA the number of serial bits to clock slip the
boundary.
If the incoming data has to be realigned, rx_std_wa_patternalign must be
reasserted to initiate another pattern alignment. Asserting
rx_std_wa_patternalign can cause the word align to lose synchronization if
already achieved. This may cause rx_syncstatus to go low.
Table 260. PCS-PMA Interface Widths and Protocol Implementations
PCS-PMA Interface Width Protocol Implementations
8 Basic
10 • Basic
• Basic rate match
• CPRI
• PCIe Gen1 and Gen2
• GigE
16 Basic
20 • CPRI
• Basic
• Basic rate match
5. Arria 10 Transceiver PHY Architecture
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
487
