Intel Arria 10 User Manual

PCS-PMA
Interface
Width
Supported Word
Aligner Modes
Supported
Word Aligner
Pattern
Lengths
rx_std_wa_patte
rnalign behavior
rx_syncstatus
behavior
rx_patterndetect
behavior
achieve
deterministic
latency on the RX
path for CPRI and
OBSAI applications.
Synchronous State
Machine
7, 10, 20 FPGA fabric-driven
rx_std_wa_patt
ernalign signal
has no effect on
word alignment.
Stays high as long
as the
synchronization
conditions are
satisfied.
Asserted high for
one parallel clock
cycle when the word
alignment pattern
appears in the
current word
boundary.
5.3.2.1.6. Word Aligner RX Bit Reversal Feature
The RX bit reversal feature reverses the order of the data received from the PMA. It is
performed at the output of the Word Aligner and is available even when the Word
Aligner is disabled. If the data received from the PMA is a 10-bit data width, the bit
reversal feature switches bit [0] with bit [9], bit [1] with bit [8], and so on. For
example, if the 10-bit data is 1000010011, the bit reversal feature, when enabled,
changes the data to 1100100001.
5.3.2.1.7. Word Aligner RX Byte Reversal Feature
The RX byte reversal feature is available only when the PCS-PMA interface width is 16
bits or 20 bits. This feature reverses the order of the data received from the PMA. RX
byte reversal reverses the LSByte of the received data with its MSByte and vice versa.
If the data received is 20-bits, bits[0..9] are swapped with bits[10..20] so that the
resulting 20-bit data is [[10..20],[0..9]]. For example, if the 20-bit data is
11001100001000011111, the byte reversal feature changes the data to
10000111111100110000.
5.3.2.2. RX Polarity Inversion Feature
The RX polarity inversion feature inverts each bit of the data received from the PMA. If
the data received is a 10-bit data. Bit[0] content is inverted to its complement,
~bit[0], bit[1] is inverted to its complement, ~bit[1], bit[2] is inverted to its
complement, ~bit[2], and so on. For example, if the 10-bit data is 1111100000, the
polarity inversion feature inverts it to 0000011111.
5. Arria 10 Transceiver PHY Architecture
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
490

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
