Intel Arria 10 User Manual

Reconfigur
ation
Address
(HEX)
Reconfigur
ation Bit
Attribute Name Related
Addresses
Attribute
Encoding
Bit
Encoding
Description
[6] prbs_clken prbs_clk_dis 1'b0 Disable PRBS generator
clock
prbs_clk_en 1'b1 Enable PRBS generator
clock
0x007 [7:4] prbs_gen_pat 0x8 prbs_7 4'b0001 Enable PRBS7 pattern
prbs_9 4'b0010 Enable PRBS9 pattern
prbs_15 4'b0100 Enable PRBS15 pattern
prbs_23 4'b1000 Enable PRBS23 pattern
prbs_31 4'b0000 Enable PRBS31 pattern
0x008 [4] prbs_gen_pat 0x7 prbs_7 1'b0 Enable PRBS7 pattern
prbs_9 1'b0 Enable PRBS9 pattern
prbs_15 1'b0 Enable PRBS15 pattern
prbs_23 1'b0 Enable PRBS23 pattern
prbs_31 1'b1 Enable PRBS31 pattern
[6:5] tx_pma_data_sel 0x6 prbs_pat 2'b00 Enable PRBS generator
0x110 [2:0] ser_mode sixty_four_bit 3'b011 64-bit mode
ten_bit 3'b100 10-bit mode
0x111 [4:0] x1_clock_source_
sel
0x119 xn_non_bonding
(6
3)
5'b11000 Enables xn non bonding
Table 293. Register Map for PRBS Checker for bonded and non bonded designs
Reconfiguratio
n Address
(HEX)
Reconfiguratio
n Bit
Attribute Name Related
Addresses
Attribute
Encoding
Bit
Encoding
Description
0x00A [7] prbs_clken prbs_clk_dis 1'b0 Disable PRBS checker
clock
prbs_clk_en 1'b1 Enable PRBS checker
clock
0x00B [3:2] rx_prbs_mask prbsmask1024 2'b11 Counter threshold to
1023
prbsmask128 2'b00 Counter threshold to
127
prbsmask256 2'b01 Counter threshold to
255
prbsmask512 2'b10 Counter threshold to
511
[7:4] prbs_ver 0xC prbs_7 4'b0001 Enable PRBS7 pattern
continued...
(63)
You must read and save the value in the register 0x111[5:0] before changing the
x1_clcok_source_sel setting to xN non bonding. To disable the PRBS generator, write the
original values back into the read-modify-write address.
6. Reconfiguration Interface and Dynamic Reconfiguration
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
552
