Other Optional Boards
Gem-5 User’s Manual 353
The Auxiliary Sensor Board connectors TB7 to TB22 provide connection points for
the various system sensors and switches. The function of each terminal block is
described on the silkscreen. Refer to Table 45 on page 354.
Table 43 Sensor Polarity Switch Settings
Switch SENSOR OFF ON LED
21
SW3-1 IN 1 ACTIVE LOW ACTIVE HIGH D21
SW3-2
IN 2
ACTIVE LOW
ACTIVE HIGH
D13
SW3-3
IN 3
ACTIVE LOW
ACTIVE HIGH
D22
SW3-4 IN 4 ACTIVE LOW ACTIVE HIGH D14
SW4-1 IN 5 ACTIVE LOW ACTIVE HIGH D23
SW2-2 IN 6 ACTIVE LOW ACTIVE HIGH D15
SW3-3 IN 7 ACTIVE LOW ACTIVE HIGH D24
SW4-4 IN 8 ACTIVE LOW ACTIVE HIGH D16
SW5-1
IN 9
ACTIVE LOW
ACTIVE HIGH
D25
SW5-2
IN 10
ACTIVE LOW
ACTIVE HIGH
D17
SW5-3 IN 11 ACTIVE LOW ACTIVE HIGH D26
SW5-4 IN 12 ACTIVE LOW ACTIVE HIGH D18
SW6-1 IN 13 ACTIVE LOW ACTIVE HIGH D27
SW6-2 IN 14 ACTIVE LOW ACTIVE HIGH D19
SW6-3 IN 15 ACTIVE LOW ACTIVE HIGH D28
SW6-4
IN 16
ACTIVE LOW
ACTIVE HIGH
D20
Table 44 Relay Output Switch Settings
Switch Relay OFF ON LED
22
SW1-1
Relay 1
(TB1)
NORMALLY ENERGIZED
NORMALLY
DE-ENERGIZED
D1
SW1-2
Relay 2
(TB2)
NORMALLY ENERGIZED
NORMALLY
DE-ENERGIZED
D3
SW1-3
Relay 3
(TB3)
NORMALLY ENERGIZED
NORMALLY
DE-ENERGIZED
D5
SW1-4
Relay 4
(TB4)
NORMALLY ENERGIZED
NORMALLY
DE-ENERGIZED
D7
SW2-1
Relay 5
(TB5)
NORMALLY ENERGIZED
NORMALLY
DE-ENERGIZED
D9
SW2-2
Relay 6
(TB6)
NORMALLY ENERGIZED
NORMALLY
DE-ENERGIZED
D11
21
LED indicator on the board is ON when associated signal is active.
22
LED indicator on the board is ON when associated signal is active.
