Model Selection and Configuration
Gem-5 User’s Manual 35
Table 6 Access Configuration Typical Defaults (by Sensor Board)
Section
Setting
254 ID 2 (Sensor Board) 253 ID 3 (Auxiliary Sensor Board)
General
Manual Stop Measurement
– Input
“None”
“253 : TB18 IN 7”
(when Hot Side Default
Configuration is not “None”
Supervisor Security Access
– Input
“None” “None”
UPS ON – Input
“None” “None”
Cold to Hot
“No” “No”
Hot Side
Default Configuration
When not “None” the items below are
(otherwise negate all)
When not “None” the items below are
(otherwise negate all)
Lock – Output
“TB05 Relay 3” “None”
Close – Output
“None” “253 : TB02 OUT 2”
Reset – Output
“None” “253 : TB03 OUT 3”
Closed – Input
“TB16 Spare 3 Latched” “253 : TB15 IN 1”
Opened – Input
“None” “253 : TB07 IN 2”
Fault – Input
“None” “253 : TB16 IN 3”
Security Key – Input
“None” “None”
Access Key – Input
“None” “None”
Access Scanner – Input
“None” “None”
Open Barrier
“Normal” “Normal”
Service Open
“YES” “YES”
Alarm Test Open
“YES” “YES”
Security Supervisor Open
“YES” “YES”
Hot Side Security Key Open
“YES” “YES”
Cold Side Security Key
Open
“YES” “YES”
Contaminated Go Back
Open
"After Remove Badge" "After Remove Badge"
Resume Contaminated
Open
"After Resume Contaminated" "After Resume Contaminated"
Cold Side
Default Configuration
When not “None” the items below are
(otherwise negate all)
When not “None” the items below are
(otherwise negate all)
Lock – Output
“TB06 Relay 4” “253 : TB04 OUT 4”
Close – Output
“None” “253 : TB05 OUT 5”
Reset – Output
“None” “253 : TB06 OUT 6”
Closed – Input
“TB17 Spare 4 Latched” “253 : TB19 IN 9”
Opened – Input
“None” “253 : TB11 IN 10”
Fault – Input
“None” “253 : TB20 IN 11”
