ANSI Hardware Installation Manual 7360 ISAM FX-16 shelf cabling
Issue: 09 3HH-12893-AAAA-TCZZA 103
DRAFT
Procedure 15 To connect the grounding cable
Use the following procedure to connect the grounding cable.
1 Route the grounding cable to the right or left side of the shelf.
2 Connect the dual-lug to the grounding cable connection point as shown in Figure 35.
3 STOP. This procedure is complete.
6.4 Rack grounding connection
The 7360 ISAM FX-16 requires a 2 AWG rack frame grounding lug for the rack
grounding connection.
Procedure 16 To connect the rack ground
1 Prepare the frame grounding cable.
2 Following local practices, route the grounding cable to the top of the rack.
Danger — Possible risk of personal injury or damage to equipment due
to inaccurate or faulty ground cabling.
Inaccurate grounding connection can cause electric shock or equipment
damage when the rack power is switched on.
Note — The grounding cable nuts should be tightened with a torque of
13.28 to 17.7 lbf-in. (1.5 to 2.0 N.m).
Danger 1 — Rack or frame must be suitably connected to the
office grounding network in accordance with Article 250 of the
National Electrical Code (NEC) to ensure UL and CSA
compliance. If outside the United States, ground per local
electrical codes and practices.
Danger 2 — Possible risk of personal injury or damage to
equipment due to inaccurate or faulty ground cabling.
Inaccurate grounding connection can cause electric shock or
equipment damage when the rack power is switched on.
