Installing a 7360 ISAM WM shelf
396
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
21.3 Mounting the 7360 ISAM WM shelf in a 23 in.
rack
The 7360 ISAM WM shelf can be mounted vertically in a 23 in. rack.
The 7360 ISAM WM is suitable for the following:
• rack mounting on concrete floors or other non-combustible surfaces with the use
of a drip tray
• use in an installation using an IBN or a CBN
• use in:
• network telecommunication facilities
• locations where the NEC applies
• OSP
21.3.1 7360 ISAM WM rack mounting
The 7360 ISAM WM shelf can be mounted vertically in a standard 23 in. rack with a
21.5 in. opening.
21.3.1.1 7360 ISAM WM rack mounting configurations
Table 16 describes the vertical rack mounting configuration for a 7360 ISAM WM
shelf in a 23 in. rack, used in conjunction with a 7360 ISAM FX-16 shelf and
associated components.
Warning — The 7360 ISAM WM is intended to be installed in a
restricted access location (RAL) in accordance with the
applicable requirements of NEC or CEC. The local authorities
have jurisdiction. This unit is intended to be installed by
qualified service personnel only.
Caution — Due to high heat dissipation for the 7360 ISAM WM
shelf, special shelf room cooling may be required, or aisle
spacing may need to be increased.
Caution — The 7360 ISAM WM drip tray must be used in a
vertical mount installation to meet NEBS preferred airflow
specifications (air flows in the front, and out the rear of the
shelf).
