Nokia 7360 Intelligent Services Access Manager FX Series User Manual

ANSI Hardware Installation Manual Fiber optic cable management in the
7360 ISAM WM shelf
Issue: 09 3HH-12893-AAAA-TCZZA 431
DRAFT
24 Fiber optic cable management in
the 7360 ISAM WM shelf
24.1 Overview
24.2 Managing fiber optic cables
24.3 Routing fiber optic cables
24.1 Overview
This chapter describes the fiber optic cable management for the 7360 ISAM WM
shelf.
The fiber optic cable management strategy is based on the following concepts:
1 To route the fiber optic cables out of the rack toward the vertical cable channels
located on both sides of the front of the rack.
2 To route the fiber optic cables within the 7360 ISAM WM shelf toward the
dedicated fiber outlets of the shelf.
3 To protect the fiber optic cables using optional bending protection items.
The 7360 ISAM WM fiber optic cable management strategy incorporates the
following hardware:
• Fiber management guides to provide proper fiber optic cable handling, support
and control.
Figure 255 shows a view of the 7360 ISAM WM fiber guiding elements of the fiber
management kit.
Note — see Appendix 27 “Fiber optic handling and acceptance
criteria”for more information.
