Nokia 7360 Intelligent Services Access Manager FX Series User Manual

ANSI Hardware Installation Manual Installing cards in the 7360 ISAM FX-4 shelf
Issue: 09 3HH-12893-AAAA-TCZZA 365
DRAFT
19 Installing cards in the
7360 ISAM FX-4 shelf
19.1 Overview
19.2 Shelf areas and slot positions
19.3 Dummy front panels
19.4 Recommended tools
19.5 Guideline for card installation
19.6 Installation procedures
19.1 Overview
This chapter provides the procedures to install field-replaceable units (FRUs) in a
7360 ISAM FX-4 shelf.
19.2 Shelf areas and slot positions
Figure 209 shows the NT and LT card slot positions in a 7360 ISAM FX-4 shelf.
Figure 209 NT and LT slot positions in 7360 ISAM FX-4
Note — For an overview of the supported cards, see the
7360 ISAM FX Product Information Guide.
LT 4
LT 3
LT 2
LT 1
NT A
NT I/O
NT B
NGFC-G
FAN
22405
