ANSI Hardware Installation Manual Installing a 7360 ISAM FX-4 shelf

Issue: 09 3HH-12893-AAAA-TCZZA 339

DRAFT

Figure 191 Mounting the 7360 ISAM FX-4 shelf assembly vertically in a 23 in.

rack

10 STOP. This procedure is complete.

17.4 Installing or replacing a fan unit in a

7360 ISAM FX-4 shelf

The fan unit is a field-replaceable unit with wide-voltage-range fans and an alarm

interface board and (optional) fan filter. The unit is installed in the shelf fan area and

plugs directly into the backplane connectors providing connection. The front panel

includes a single red alarm LED that lights up if fan failure occurs.

One version of the fan unit is available:

• intelligent fan unit (BFAN-X)

Note — See Chapter 18 “7360 ISAM FX-4 shelf cabling” for

7360 ISAM FX-8 shelf cabling information.
